The Foodline sunflower oil press machine is a device that squeezes oil out of sunflower seeds. It uses mechanical pressure to get a high amount of oil while keeping the oil good quality. This machine is perfect for small farm, local oil workshop, or large commercial oil processing factory.
The extracted oil can be filtered and refined depending on your production goals.
Technical Parameters of Sunflower Oil Extraction Machine
| Model / Parameter | 6YL-80ZD I | 6YL-100ZD I | 6YL-120ZD I | 6YL-150ZD I |
|---|---|---|---|---|
| Handling capacity (rapeseed) | 80-160 kg/h | 150-260 kg/h | 260-400 kg/h | 400-500 kg/h |
| Screw press diameter | 80 mm | 100 mm | 120 mm | 150 mm |
| Inner circle diameter of pressing chamber (approx.) | 82 mm | 102 mm | 122 mm | 152 mm |
| Main motor power | 5.5 kW | 7.5 kW | 11 kW | 22 kW |
| Heating power | 3 kW | 3.5 kW | 4 kW | 5 kW |
| Vacuum pump power | 1.1 kW | 1.1 kW | 1.1 kW | 1.5 kW |
| Vacuum pump capacity | 10 L | 10 L | 10 L | 15 L |
| Weight | 610 kg | 950 kg | 1020 kg | 1810 kg |
| Screw speed | 71 r/min | 49 r/min | 49 r/min | 42 r/min |
| Overall dimensions (mm) | 1650*1300*1600 | 2020*1315*1570 | 2060*1345*1570 | 2700*2910*1635 |
How Does a Sunflower Oil Press Machine Work?
The sunflower oil extraction process typically includes several stages:
1. Seed Cleaning
Remove stones, dust, metal, and other impurities before pressing.
2. Dehulling (Optional)
Some processors remove sunflower seed shells to improve oil yield.
3. Roasting/Conditioning
Heating sunflower seeds can improve oil extraction efficiency.
4. Oil Pressing
The screw oil press compresses seeds to extract crude sunflower oil.
5. Oil Filtration
The oil passes through a filter machine to remove impurities.
6. Oil Cake Discharge
The leftover cake can be sold as animal feed.
Features of Sunflower Oil Press Machines
- High Oil Yield – Gets more oil from the seeds and wastes less.
- Runs Continuously – Can run for long hours without stopping.
- Long-Lasting Screw Shaft – Made from strong, wear-resistant steel that lasts a long time.
- Easy to Use – Simple controls work well for both beginners and experienced operators.
- Saves Energy – Uses less power, which lowers production costs.
Start Your Sunflower Oil Business Today
A high-quality sunflower oil press machine helps you produce premium edible oil with greater efficiency and profitability.
Contact us today for pricing, machine videos, and customized sunflower oil production solutions.
